Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler

Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler
Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler

Large Image :  Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler

Product Details:
Place of Origin: China
Brand Name: WILFORD
Certification: CE,ASME
Model Number: WQ
Payment & Shipping Terms:
Minimum Order Quantity: 1 stand
Price: Negotiable
Packaging Details: Wooden box package
Delivery Time: 15-20 working days
Payment Terms: L/C, T/T
Supply Ability: 25 stand/stands per Month

Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler

Description
Rated Evaporation: 0.5-1t/h Rated Working Pressure: 0.8Mpa
Staturated Steam Temperature: 174℃ Usage: Steam Outputing
Style: Vertical Fuel: Oil-fired,Gas-fired,natural Gas,lpg
Pressure: Low Pressure Type: Natural Circulation
Product Name: Diesel Oil Fired Steam Boiler Output: Steam
High Light:

0.8Mpa Diesel Fired Steam Boiler

,

1T/H Diesel Fired Steam Boiler

,

1T/H biomass fired steam boiler



0.5-1T/h Insuatrial Diesel Oil Fired Steam Boiler





Diesel Oil Fired Steam Boiler introduction



★  0.5-1T/h Insuatrial Diesel Oil Fired Steam Boiler ,it is fuelled by dieael oil,natural gas ,LPG and so on.



★ Imported  burner or low nitrogen burner. Adopts German high quality pressure gauge .



★  Built-in efficient soda separation device.Horizontal furnace structure,



★  Schneider main electric appliance.



★   LCD display controller, can display the running status, fault alarm, type and other parameters.



★  Optional all-premixed surface burner; Low nitrogen 30 mg; Optional Siemens PLC controller.



★ The steam capacity gas fired steam generator boiler can be exempted from inspection;



★ Vertical structure, compact and beautiful, elegant style, classic color, save room space and easily installation.




Diesel Oil Fired Steam Boiler Parameter



                                                   WQ Vertical Oil(gas)Fired Steam Boiler
Type WQ-500 WQ-500LX WQ-1000 WQ-1000LX
Project Unit
Rated evaporation kg/h 500 1000 500 1000
Rated working pressure MPa 0.8 0.8 0.8 0.8
Staturated steam temperature 174 174 174 174
Fuel consumption Light diesel oil kg/h 38 38 75 75
Natural gas Nm³/h 15 15 30 30
a Main steam valve diameter DN 40 40 50 50
b Safety valve diameter DN 50 50 50*2 50*2
c Inlet diamater DN 25 25 25 25
d Blowoff Valve diameter DN 25 25 25 25
e Chimney diameter DN 250 250 250 250
Overall size L mm 3000 3000 3600 3600
W mm 1450 1450 1800 1800
H mm 2200 2200 2200 2200
Weight kg 1800 1800 2900 2900




Diesel Oil Fired Steam Boiler Advantage



  • Vertical structure, save room space and easily installation.



  • Adopts German high quality pressure gauge



  • ​Imported burner or low nitrogen burner.



  • ​Multiple chain protection



  • Full combustion, low energy consumption



  • Environmentally friendly boiler, Safety and energy saving.




Diesel Oil Fired Steam Boiler picture





Natural Circulation 1T/H 0.8Mpa Diesel Fired Steam Boiler 0





Application Scope



  • It is widely used in hospitals, schools, textile mills, garment factories, clothing supermarkets, garment factories, dry cleaners, restaurants.



  • Hotels, restaurants, hotels, canteens, restaurants, food factories, beverage factories, soy products factories, canneries, wineries.



  • Pharmaceutical factory, packaging factory, building material factory, paint factory, beauty salon, bath center, sauna, steam room, baby swimming pool, etc.



After - sales service



  • Provide on-site reconnaissance and guide the installation.



  • commissioning and personnel training



  • A big team in responsible for the after-sale service and is always at customers’ service.



  • We will supply after service 24 hours,customer can contact us any time.
