174 Degree 1T/H Low Pressure Natural Gas Fired Steam Boiler

174 Degree 1T/H Low Pressure Natural Gas Fired Steam Boiler
174 Degree 1T/H Low Pressure Natural Gas Fired Steam Boiler 174 Degree 1T/H Low Pressure Natural Gas Fired Steam Boiler 174 Degree 1T/H Low Pressure Natural Gas Fired Steam Boiler

Large Image :  174 Degree 1T/H Low Pressure Natural Gas Fired Steam Boiler

Product Details:
Place of Origin: China
Brand Name: WILFORD
Certification: CE,ASME
Model Number: WQ
Payment & Shipping Terms:
Minimum Order Quantity: 1 stand
Price: Negotiable
Packaging Details: Wooden box package
Delivery Time: 15-20 working days
Payment Terms: L/C, T/T
Supply Ability: 25 stand/stands per Month

174 Degree 1T/H Low Pressure Natural Gas Fired Steam Boiler

Description
Rated Evaporation: 1t/h Rated Working Pressure: 0.8Mpa
Staturated Steam Temperature: 174℃ Usage: Steam Outputing
Style: Vertical Fuel: Oil-fired,Gas-fired,natural Gas,lpg
Pressure: Low Pressure Type: Natural Circulation
Product Name: Diesel Oil Fired Steam Boiler Output: Steam
High Light:

1T/H natural gas fired boiler

,

1T/H low pressure steam boiler

,

0.8Mpa low pressure steam boiler



Best Price 1T/H Natural Gas / Diesel Oil Fuel Steam Boiler For Industry





Industrial Steam Boiler introduction



  • Adopts German high quality pressure gauge,​Imported burner or low nitrogen burner.Small heat loss and high thermal efficiency.



  • Multiple chain protection,Full combustion, low energy consumption,Environmentally friendly boiler, Safety and energy saving.



  • The furnace structure has good heat absorption effect, the combustion efficiency is 95%.



  • Energy-saving device and condensing device composed of laser finned welded pipe with advanced welding technology.



  • High thermal efficiency and compact structure can greatly increase the heat exchange area, fully enhance the heat transfer of the flue gas and improve the efficiency of the boiler.


Industrial Steam Boiler Parameter



                                                   WQ Vertical Oil(gas)Fired Steam Boiler
Type WQ-500 WQ-500LX WQ-1000 WQ-1000LX
Project Unit
Rated evaporation kg/h 500 1000 500 1000
Rated working pressure MPa 0.8 0.8 0.8 0.8
Staturated steam temperature 174 174 174 174
Fuel consumption Light diesel oil kg/h 38 38 75 75
Natural gas Nm³/h 15 15 30 30
a Main steam valve diameter DN 40 40 50 50
b Safety valve diameter DN 50 50 50*2 50*2
c Inlet diamater DN 25 25 25 25
d Blowoff Valve diameter DN 25 25 25 25
e Chimney diameter DN 250 250 250 250
Overall size L mm 3000 3000 3600 3600
W mm 1450 1450 1800 1800
H mm 2200 2200 2200 2200
Weight kg 1800 1800 2900 2900





Industrial Steam Boiler



  • Medical industry: disinfection, heating, canteen, equipment heating, equipment purification, cooking medicinal materials, medicinal materials extraction, hospital dry cleaning machine, hospital laundry room disinfection.



  • Cleaning industry: steam cleaning, oil cleaning, seamless pipe cleaning, oilfield equipment cleaning, aluminum alloy mold cleaning, industrial machine cleaning, engine cleaning, oil pipeline filter cleaning, automotive parts cleaning, etc.



  • Greenhouse farming industry: heating, temperature control, antifreeze, breeding, etc.



  • Washing ironing industry: dry washer, dryer and washing machine, dryer, ironing machine, electric iron, and other ancillary equipment.



  • Food machinery industry: tofu machine, steam box, sterilization pot, packing machine, coating equipment, sealing machine, such as supporting the use of equipment.
